Screw connection is a kind of practical removable fixed connection, which has the advantages of simple structure, reliable connection, convenient assembly and disassembly, and is widely used in mechanical equipment.
一、 Assembly of stud bolts
Fig. 1 Fixing Form of Stud Bolts
1. In order to prevent the bolt from locking when screwing in, and to facilitate removal and repeated installation, the stud bolt can be coated with lubricating oil.
2. The axis of the stud bolt must be perpendicular to the body surface. During installation, use a square ruler to check. If the axis is slightly inclined to the surface of the machine body, use a tap to correct the threaded hole, or use the installed stud to correct; If the inclination is large, do not force correction to prevent the reliability of bolted connection from being damaged.
3. Ensure that the connection between bolts and engine body is tight enough.
4. Common methods for screwing in stud bolts:
① Screw in with two nuts. As shown in Fig. 2a), lock the two nuts on the stud, and then pull the upper nut to screw the stud into the screw hole.
② Screw in with a long nut. As shown in Fig. 2b), the upper screw is used to prevent the relative rotation between the long nut and the stud, and then pull the long nut, and the stud can be screwed in. Loosen the stop screw to remove the long nut.
Fig. 2 Method of screwing in stud bolts
③ Screw in with special tool. The figure shows the special tool for screwing in the stud. The three rollers are placed in the cavity of the tool body, and their circumferential and axial positions are determined by the limit sleeve 4. The limit sleeve is fixed by the groove retainer ring, and the loosening and clamping of the roller are controlled by the inner cavity curve of the tool body. The roller shall be clamped on the polished rod of the bolt, and the stud can be screwed in by turning the tool body in the direction of the arrow as shown in Figure 3, otherwise the bolt can be loosened. The groove curve direction of the tool for removing stud bolts shall be opposite to that of the tool for screwing in.
Fig. 3 Special Tools for Stud Screw in
1. The fitting surface between the nut or screw and the fastener shall be smooth and flat to avoid additional bending moment during tightening.
2. The tightening torque shall be strictly controlled. Excessive tightening torque will stretch or even break the bolt or screw, or cause deformation of the connected parts. When the tightening force is insufficient, the connection is easy to loosen, affecting the reliability.
3. After the nut is tightened, the spring washer shall contact with the nut and the surface of the connected piece on the entire circumference. The length of thread exposed outside the nut shall not be less than two threads, but shall not be too long, generally 3~5mm.
4. When tightening the group nuts, they must be tightened in a certain order, step by step, or the bolts and the machine body will be deformed due to uneven stress. When tightening the group nuts with rectangular arrangement, start from the middle and gradually expand to both sides, as shown in Figure 4. When tightening round or square arranged group nuts, they must be tightened symmetrically, as shown in Figure 5.
Fig. 4 Sequence of tightening group nuts in rectangular arrangement
Fig. 5 Sequence of tightening round or square arranged group nuts
